13" Vari-Speed Gear Head Milling Machine

In stock
Model No
9680159
$2,346.00
13" Vari-Speed Gear Head Milling Machine
  • Rigid box column with hardened and ground hand scraped dovetail ways provide accurate head positioning with minimum deflection and vibration
  • All gear drive transmission with 2 step gear box
  • The milling head can be tilted right or left up to 90 degrees
  • Precision machine tool spindle equipped with taper roller bearings and a spindle concentricity of 0.0005" at the spindle nose
  • Cross slide table is precision ground with t-slots, adjustable limit stops, scale and two metal adjusting hand wheels
  • Interlocking spindle safety guard
  • Draw bar
  • Safety electrical system with emergency stop button and 24 volts at all the switches
  • Equipped with: Halogen work light, depth stop, interlocking spindle safety guard and draw bar

Product Details

Palmgren's 13" variable speed gear head milling machine delivers precision, power and versatility to handle a wide range of small workpiece metalworking applications. The all gear drive transmission delivers full power at any speed driving the cutting tools at nearly 100% of the available horsepower. Equipped with a high performance brushless DC motor permanent current control and infinitely variable speed providing the broadest range of spindle speeds to fit any application.
More Information
Speed Range 100 to 3000
Spindle 2MT with 3/8"-16 Draw Bar
Motor HP 5/8
Operating Pressure (PSI) Manual
Optional Accessories Item # 9670107 Heavy duty floor stand
Overall Dimensions (LxWxH) 19" x 18" x 33"
Spindle Taper 2MT
T-Slot Size/Distance/Quantity 3/8"
Voltage 115
Spindle Travel 2"
Swing 13-1/2"
Table Dimensions 15-3/4" x 4-3/4"
Master Pack Height (in) 19
Master Pack Length (in) 33
Master Pack Weight (lbs) 172
Master Pack Width (in) 18
Milling Machines Type Gear Head
Phase Single
Warranty 3 Year
UPC 726896801599
Country of Origin CN
Brand Palmgren
Unit of Measure Each
Product Weight (lbs) 135
Head Gear Driven
Head Travel Gear Driven
Longitudinal Travel 8-21/32"
Cross Slide Travel 6-3/8"
End Milling Capacity 13/16
Face Milling Capacity 2-1/2"
